MIL-DTL-8783D
TABLE I. Qualification inspection.
Requirement
Inspection
Title
paragraph
paragraph
Examination of product
Minimum adjustment range
Load deflection 1/
Band tensile load 1/
1/ Destructive test.
4.5 Conformance inspection.
4.5.1 Inspection of product for delivery. Inspection of product for delivery shall consist of sampling
tests.
4.5.1.1 Sampling inspection. Sampling inspection shall consist of the inspections specified in table
II. These tests shall be performed on a production lot basis. Samples shall be selected to form an
inspection sample (see 4.5.3).
TABLE II. Sampling inspection.
Requirement
Inspection
Title
paragraph
paragraph
Examination of product
Minimum adjustment range
4.5.1.2 Sampling inspection defects. If one or more defects are found in the inspection sample,
then the production lot shall be screened for that particular defect and defects removed. A second
inspection sample shall be selected from the production lot and all sampling tests again performed. If
one or more defects are found in the second inspection sample, the production lot shall be rejected and
shall not be supplied to this specification.
4.5.2 Production lot. A production lot shall consist of clamps of the same size and type
manufactured on the same production line(s) by means of the same production technique, materials,
controls, and design during the same continuous production run.
4.5.3 Inspection sample. The inspection sample shall be product selected at random from the
production lot without regard to quality and shall be the size specified in table III.
6
