MIL-DTL-85061C
4.3 Conformance inspection. Conformance inspection shall consist of:
a. Individual inspection (see 4.3.1).
b. Sampling inspection (see 4.3.2).
4.3.1 Individual inspection. Each coupling shall be visually examined to determine that
the coupling complies with the requirements specified in 4.5.1. Any coupling failing to pass the
examination shall be rejected.
TABLE IV. First article inspection.
Item
Test description
Requirement paragraphs
Test paragraphs
1
Visual examination
3.6.1
4.5.1
2
Proof pressure
3.6.2
4.5.2
3
Leakage
3.6.3
4.5.3
4
Fuel resistance
3.6.4
4.5.4
5
Vibration
3.6.5
4.5.5
6
Repeated assembly
3.6.6
4.5.6
7
Salt fog
3.6.7
4.5.7
8
Flexure
3.6.8
4.5.8
9
Surge pressure
3.6.9
4.5.9
10
Burst pressure
3.6.10
4.5.10
11
Workmanship
3.11
--
12
Inspection for delivery
3.12
4.5.1.2
4.3.2 Sampling inspection. The sample size shall be selected in accordance with
ANSI/ASQ Z1.4 inspection level I, acceptable quality level (AQL) as specified in the contract
and shall pass the tests listed in table V except tests shall be performed at room temperature. If
the sample fails to pass this test, the lot represented by this sample shall be rejected. The tested
coupling shall be discarded.
12
