MS24591 Socket, Adapter, Hose To Tube, Reusable, Hydraulic, Fuel And Oil Lines, 1 Through 2 Inches Tubing Sizes

Pages 1 - 2 - 3 - 4 - 5

Dash number

A inches (mm)

B inches (mm)

C inches (mm)

D inches (mm)

E inches (mm)

F inches (mm)

G inches (mm)

H inches (mm)

J inches (mm)

-16

1.671 (42.44)

1.651 (41.94)

1.546 (39.27)

1.516 (38.51)

1.421 (36.09)

1.391 (35.33)

1.453 (36.91)

1.423 (36.14)

1.015 (25.78)

1.002 (25.45)

1.280 (32.51)

1.260 (32.00)

1.290 (32.77)

1.175 (29.85)

1.340 (34.04)

1.330 (33.78)

-20

1.760 (44.70)

1.740 (44.20)

1.921 (48.79)

1.891 (48.03)

1.765 (44.83)

1.735 (44.07)

1.765 (44.83)

1.735 (44.07)

1.265 (32.13)

1.252 (31.80)

1.373 (34.87)

1.353 (34.37)

1.555 (39.50)

1.430 (36.32)

1.560 (39.62)

1.550 (39.37)

-24

1.860 (47.24)

1.830 (46.48)

2.124 (53.95)

2.094 (53.19)

1.937 (49.20)

1.907 (48.44)

1.953 (49.61)

1.923 (48.84)

1.515 (38.48)

1.502 (38.15)

1.465 (37.21)

1.445 (36.70)

1.800 (45.72)

1.675 (42.55)

1.810 (45.97)

1.795 (45.59)

-32

2.270 (57.66)

2.230 (56.64)

2.640 (67.06)

2.600 (66.04)

2.460 (62.48)

2.420 (61.47)

2.460 (62.48)

2.420 (61.47)

1.948 (49.48)

1.940 (49.28)

1.860 (47.24)

1.820 (46.23)

2.290 (58.17)

2.160 (54.86)

2.330 (59.18)

2.315 (58.80)
