MIL-DTL-52525/17C
TABLE II. O-ring legacy replacements for AN6227. 1/ 2/ 3/
Width
ID
Dash
PIN
(T or d2)
(d1)
Comments
size
Inches (mm)
Inches (mm)
-8
AN6227-15
.0934 (2.37)
.750 (19.05)
Originally MIL-DTL-52525/17
-12
AN6227-19
.0934 (2.37)
1.000 (25.40)
called out the AN6227 and
-16
AN6227-24
.125 (3.18)
1.313 (33.35)
AN6230 PIN's. AN6227 and
-20
AN6227-27
.125 (3.18)
1.500 (38.10)
AN6230 are cancelled and
-24
AN6230-3
.125 (3.18)
1.875 (47.63)
superseded by
SAE-AS28775.
-32
AN6230-6
.125 (3.18)
2.250 (57.15)
Replacement PIN for the AN6227
Width
ID
Dash
PIN
(T or d2)
(d1)
Comments
size
Inches (mm)
Inches (mm)
.135-.143
.728 - .0740
-8
SAE-AS28775-210
(3.43 - 3.63)
(18.49 - 1.880)
.135-.143
.978 - .0990
-12
SAE-AS28775-214
(3.43 - 3.63)
(24.84 - 2.514)
.135-.143
1.290 - 1.302
The SAE-AS28775 PIN is a
-16
SAE-AS28775-219
(3.43 - 3.63)
(32.76 - 33.070)
replacement for AN6227 and
.135-.143
1.478 - 1.490
AN6230.
-20
SAE-AS28775-222
(3.43 - 3.63)
37.54 - 37.846)
.205-.215
1.840 - 1.860
-24
SAE-AS28775-328
(5.21 - 5.46)
(46.74 - 47.24)
.205-.215
2.215 - 2.235
-32
SAE-AS28775-331
(5.21 - 5.46)
(56.26 - 56.77)
1/ Dimensions are in inches.
2/ Metric equivalents are given for information only.
3/ The width and ID columns are dimensions from the PIN in column 2.
5
