MIL-DTL-52525/12D
TABLE III. Harmonization to SAE-J516 cross reference PIN. 1/
SAE J518-2 PIN
PIN
SAE PIN
Flange head only
M52525/12-8-8
SAE J516 8-8 391454
SAE J518-2-8-0562
M52525/12-12-12
SAE J516 12-12 391454
SAE J518-2-12-0562
M52525/12-12-16
SAE J516 12-16 391454
SAE J518-2-16-0562
M52525/12-16-16
SAE J516 16-16 391454
SAE J518-2-16-0562
M52525/12-16-20
SAE J516 16-20 391454
SAE J518-2-20-0562
M52525/12-20-20
SAE J516 20-20 391454
SAE J518-2-20-0562
M52525/12-20-24
SAE J516 20-24 391454
SAE J518-2-24-0562
M52525/12-24-24
SAE J516 24-24 391454
SAE J518-2-24-0562
M52525/12-32-32
SAE J516 32-32 391454
SAE J518-2-32-0562
1/ Material and finish designators are omitted from PIN's see table I and
SAE-J846.
Notes:
1. For design feature purposes, this standard takes precedence over the procurement document
referenced herein. Referenced documents shall be of the issue in effect on the date of
invitation for bid.
2. In the event of a conflict between the text of this standard and the referenced cited herein, the
text of this standard shall take precedence.
Changes from previous issue. Marginal notations are not used in this revision to identify changes
with respect to the previous issue, due to the extent of the changes.
Referenced documents. In addition to MIL-DTL-52525, this document references the following:
MIL-DTL-81706
SAE-AMS2488
MIL-A-8625
ASTM B633
SAE-AMS2700
MIL-DTL-16232
ASTM B695
SAE-AS4841
MIL-DTL-52471
ASTM F1136
SAE-J516
MIL-DTL-52471/5
SAE-AMS-C-81562
SAE-J517
MIL-DTL-52525/2
SAE-AMS-QQ-P-416
SAE-J518
MIL-DTL-52525/16
MIL-DTL-52525/17
SAE-AMS2417
SAE-J846
5
