MIL-DTL-52525/12D
C max
D min
PIN
inches (mm)
inches (mm)
M52525/12-8-8
1.38 (35.05)
1.27 (32.26)
M52525/12-12-12
1.75 (44.45)
1.36 (34.54)
M52525/12-12-16
1.75 (44.45)
1.36 (34.54)
M52525/12-16-16
2.06 (52.32)
1.61 (40.89)
M52525/12-16-20
2.06 (52.32)
1.61 (40.89)
M52525/12-20-20
2.63 (66.80)
1.80 (45.72)
M52525/12-20-24
2.63 (66.80)
1.80 (45.72)
M52525/12-24-24
2.94 (74.68)
2.08 (52.83)
M52525/12-32-32
3.50 (88.90)
2.44 (61.98)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. All dimensions not shown shall be in accordance with SAE-J516 and SAE-J518-1 as applicable.
4. SAE-J516 type, for use with SAE-J517, type 100R2 hose coupled to port using SAE-J518 split
flange type
FIGURE 1. Fitting, screw-on to 4-bolt split-flange, 90° bent tube - Continued.
REQUIREMENTS:
Fittings shall be accordance with figure 1 and tables I and II.
The fittings described herein are for use with MIL-DTL-52471/5, type 100R2, double wire braided
hose and hose assemblies in accordance with MIL-DTL-52525/2.
If fittings are to be used on an oxygen hose, see MIL-DTL-52525.
Materials and finishes shall be in accordance with MIL-DTL-52525 and in table I. All finishes shall be
capable of withstanding 96 hours minimum of salt spray.
