INCH-POUNDS
MIL-DTL-25677E
22 January 2007
SUPERSEDING
MIL-DTL-25677D
18 December 1998
DETAIL SPECIFICATION
ADAPTER, CAP, AND NOZZLE, PRESSURE LUBRICATING OIL
SERVICING, AIRCRAFT, GENERAL SPECIFICATION FOR
This specification is approved for use by all Departments and
Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers the requirements for an adapter, cap, and nozzle, pressure
lubricating oil servicing, aircraft, for ground servicing of aircraft turbine engines.
1.2 Part or Identifying Number (PIN). The PIN consists of the letters MS, the PIN and dash number
from the respective slash sheet (see 1.2.1) shown in the following example:
24475
-1
MS
Dash number (see 1.2.1)
PIN (see 1.2.1)
MS prefix
1.2.1 Military Specification sheet number and dash numbers from:
MIL-DTL-25677/1 (MS24476-1or MS24476-2)
MIL-DTL-25677/2 (MS24480-1or MS24480-2)
MIL-DTL-25677/3 (MS24475-1or MS24475-2)
MIL-DTL-25677/4 (M25677/4-1, M25677/4-2, M25677/4-3 or M25677/4-4)
2. APPLICABLE DOCUMENTS
specification. This section does not include documents cited in other sections of this specification or
recommended for additional information or as examples. While every effort has been made to ensure the
completeness of this list, document users are cautioned that they must meet all specified requirements
Comments, suggestions, or questions on this document should be addressed to: Defense Supply
Center, Columbus, Attn: VAI, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to
Construction@dscc.dla.mil. Since contact information can change you may want to verify the currency of
this address information using the ASSIST Online database at https://assist.daps.dla.mil.
AMSC N/A
FSC 4730
