MIL-DTL-22263C
FIGURE 2. Tubing swaged end ferrule dimensions and configuration. 1/
TABLE III. Tubing end, swage end ferrule, variable cavity dimensions. 1/
A
B
C
D
E
F
G
Dash
Tube
+.000
+ .005
+.000
+ .005
+ .005
+ .005
No
OD
-.005
-.005
- .000
-12
0.75
0.730
0.755
0.891
0.984
0.545
-16
1.00
0.980
1.005
1.142
1.265
0.669
0.040
-20
1.25
1.230
1.256
1.392
1.515
-24
1.50
1.480
1.506
1.642
1.785
0.675
-28
1.75
1.730
1.756
1.892
2.035
5
-32
2.00
1.980
2.006
2.142
2.308
0.682
-40
2.50
2.480
2.507
2.642
2.808
0.055
-48
3.00
2.930
3.007
3.145
3.308
-56
3.50
3.455
3.507
3.650
3.819
0.712
-64
4.00
3.980
4.008
4.154
4.329
-72
4.50
4.480
4.508
4.655
4.825
-80
5.00
4.980
5.009
5.155
5.300
6
.956
0.075
-88
5.50
5.480
5.509
5.660
5.825
-96
6.00
5.980
6.010
6.165
6.340
1.001
8
