INCH-POUND
A-A-59000A
1 April 1997
SUPERSEDING
A-A-59000
9 February 1995
COMMERCIAL ITEM DESCRIPTION
STRAINERS, SEDIMENT, PIPELINE, SELF-CLEANING
(MANUAL OR AUTOMATED)
The General Service Administration has authorized the use of this
commercial item description, for all federal agencies.
1.
SCOPE
1.1 Scope. This commercial item description covers both manual and automated
self-cleaning pipeline sediment strainers.
1.2 Intended use. The strainers specified are intended for installation in
sea water piping systems on the discharge side of the pump.
2.
CLASSIFICATION
2.1 Classification. Self-cleaning strainers shall be of the following types,
classes, styles, and sizes as specified (see 7.1):
Type I - Manual hand wheel actuation.
Type II - Electric motor actuation.
Class 150 - 150 pounds per square inch gage (psig) pressure rating.
Class 250 - 250 psig pressure rating.
Style 1 - One screen, angled flow, sizes 2, 2½, and 3 inch.
Style 2 - Two screens, inline flow, sizes 2½, 3, 4, 6, 8, 10,
and 12 inch.
Style 3 - Four screens, inline flow, sizes 14 and 16 inch.
Style 4 - Six screens, inline flow, size 20 inch.
Beneficial comments recommendations, additions, deletions, clarifications
etc. and any other data which may improve this document should be sent
to: Commander, SEA 03R42, Naval Sea Systems Command, 2531 Jefferson
Davis Hwy, Arlington, VA 22242-5160.
AMSC N/A
FSC 4730
Approved for public release; distribution is unlimited.
DISTRIBUTION STATEMENT A.
