INCH-POUND MS39133G
24 May 2010
SUPERSEDING MS39133F
4 January 1999
DETAIL SPECIFICATION SHEET
ADAPTER, STRAIGHT, PIPE TO HOSE-AUTOMOTIVE AIR BRAKE HOSE
This specification is approved for use by all Departments and Agencies of the Department of Defense. The requirements for acquiring the product described herein shall consist of this specification sheet.
Inches |
mm |
0.97 |
24.64 |
1.06 |
26.92 |
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. All dimensions are "reference" dimensions.
4. For design feature purposes, this document takes precedence over acquisition documents referenced herein.
5. In the event of a conflict between the text of this specification sheet and the references cited herein, the text of this specification sheet shall take precedence.
FIGURE 1. Adapter.
AMSC N/A FSC 4730
