MIL-DTL-83798/8C
Part or Identifying Number (PIN) example:
M
83798
/8
-10
T
Material code (see table II)
Size (see figure 1)
Specification sheet number
Specification number
M prefix
M83798/7-10L-T indicates: Swivel flange 45°, 7/8 inch, material titanium annealed.
Flange, nipple, and socket material and finish code is specified in table II.
TABLE II. Flange, nipple and socket material code.
PIN code
Material
Plating finish
dash letter
Blank
Anodize
Aluminum
-T
Titanium
6AI-4V annealed
Changes from previous issue. Marginal notations are not used in this revision to identify changes
with respect to the previous issue due to the extent of the changes.
Referenced documents. In addition to MIL-DTL-83798, this document references the following:
MIL-A-8625
MS20756
MS33786
SAE-AMS4928
3
