MIL-DTL-83798/8C
Weight
A
B
(max)
(max)
Dash
Number
inch
mm
lbs.
grams
inch
mm
±.035
±0.883
-8
1.89
48.01
.370
9.398
0.103
46.72
-10
2.04
51.82
.400
10.160
0.129
58.51
-12
2.64
67.06
.468
11.887
0.168
76.20
-16
2.90
73.66
.505
12.827
0.260
117.93
-20
3.25
82.55
.569
14.453
0.380
172.37
-24
3.45
87.63
.625
15.875
0.477
216.36
-32
3.92
99.57
.734
18.644
0.795
360.61
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
FIGURE 1. Fitting, swivel flange, 45 degrees - Continued.
REQUIREMENTS:
Design and construction:
Dimensions and configuration: See figure 1.
Materials and finishes. Materials and finishes for the flange, nipple, and socket shall be as
specified in table I.
The swivel flange shall be in accordance with MS20756 and shall mate with MS33786.
TABLE I. Material and finish.
Component
Material
Finish
Socket and elbow
Aluminum in accordance with
Anodize in accordance with MIL-A-8625,
Nipple
MIL-DTL-83798
type II.
Flange
Titanium in accordance with
All components
Annealed
SAE-AMS4928 (alloy 6AI-4V)
2
