MIL-DTL-52525/9C
Color identification. Color identification shall be in accordance with SAE-AS4841.
Marking shall include the manufacturer's name or trademark, size, and hose identifier 100R10.
Location of marking is optional.
Harmonization to SAE-J516 cross reference PIN in table V is for reference only. SAE style fittings
may not have the same material/finish as required by MIL-DTL-52525 and legacy with
MIL-DTL-52471.
TABLE V. Harmonization to SAE-J516 cross reference PIN. 1/
PIN
SAE PIN
M52525/9-12-12
SAE J516 12-12 F240176
M52525/9-16-16
SAE J516 16-16 F240176
M52525/9-20-20
SAE J516 20-20 F240176
M52525/9-24-24
SAE J516 24-24 F240176
1/ Material and finish designators are omitted
from PIN's table I and SAE-J846.
Changes from previous issue. Marginal notations are not used in this revision to identify changes
with respect to the previous issue, due to the extent of the changes.
Referenced documents. In addition to MIL-DTL-52525, this document references the following:
SAE-AMS2488
ASTM B633
MIL-A-8625
SAE-AMS2700
ASTM B695
MIL-DTL-16232
SAE-AS4841
ASTM F1136
MIL-DTL-52471
SAE-J516
SAE-AMS-C-81562
MIL-DTL-52471/3
SAE-J517
SAE-AMS-QQ-P-416
MIL-DTL-81706
SAE-J846
SAE-AMS2417
ASME B1.1
