MIL-DTL-52525/5D
Q min
PIN
Bore dia.
SAE J516 d2
inches (mm)
M52525/5-4-4
.11 (2.79)
.118 (3.00)
M52525/5-4-5
.11 (2.79)
.197 (5.00)
M52525/5-4-6
.26 (6.60)
.236 (6.00)
M52525/5-5-6
.26 (6.60)
.236 (6.00)
M52525/5-6-6
.26 (6.60)
.236 (6.00)
M52525/5-6-8
.38 (9.65)
.315 (8.00)
M52525/5-8-8
.38 (9.65)
.315 (8.00)
M52525/5-8-10
.48 (12.19)
.433 (11.00)
M52525/5-10-12
.57 (14.48)
.551 (14.00)
M52525/5-12-12
.57 (14.48)
.551 (14.00)
M52525/5-12-14
.68 (17.27)
M52525/5-16-16
.78 (19.81)
7.48 (19.00)
M52525/5-20-20
1.010 (25.7)
9.84 (25.00)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Threads shall be in accordance with ASME B1.1 series with graded pitches fine (UNF) and series
with constant pitches (UNC), class 2B.
4. Dimension P to be concentric with dimension Q within .015 inch (0.38 mm) full indicator movement.
5. All dimensions not shown shall be in accordance with SAE-J516.
6. These fittings are similar to SAE-J516 type for use with SAE-J517, type 100R1 hose.
FIGURE 1. Fitting, screw-on to 37° flare, straight - Continued.
REQUIREMENTS:
Fittings shall be as specified on figure 1 and in tables I, II and III.
The fittings described herein are for use with hose in accordance with MIL-DTL-52471/4,
SAE-J517, type 100R1 steel wire reinforced, rubber covered hydraulic hose and hose assemblies in
accordance with MIL-DTL-52471/1.
If fittings are to be used on an oxygen hose, see MIL-DTL-52525.
Materials and finishes shall be in accordance with MIL-DTL-52525 and in table I. All finishes shall be
capable of withstanding 96 hours minimum of salt spray.
3
