MIL-DTL-52525/5D
Hose
Tube
Thread
Part or Identifying
C max
ID ref
OD
size
Number (PIN)
inches (mm)
inches (mm)
inches (mm)
(see note 3)
M52525/5-4-4
.250 (6.35)
.250 (6.35)
.438-20-UNF
3.00 (76.20)
M52525/5-4-5
.250 (6.35)
.313 (7.95)
.500-20-UNF
2.80 (71.12)
M52525/5-4-6
.250 (6.35)
.375 (9.53)
.563-18-UNF
2.97 (75.44)
M52525/5-5-6
.313 (7.95)
.375 (9.53)
.563-18-UNF
2.97 (75.44)
M52525/5-6-6
.375 (9.53)
.375 (9.53)
.563-18-UNF
3.32 (84.33)
M52525/5-6-8
.375 (9.53)
.500 (12.70)
.750-16-UNF
3.49 (88.65)
M52525/5-8-8
.500 (12.70)
.500 (12.70)
.750-16-UNF
3.65 (92.71)
M52525/5-8-10
.500 (12.70)
.625 (15.88)
.875-14-UNF
3.87 (98.30)
M52525/5-10-12
.625 (15.88)
.750 (19.05)
1.063-12-UNC
4.32 (109.73)
M52525/5-12-12
.750 (19.05)
.750 (19.05)
1.063-12-UNC
4.76 (120.90)
M52525/5-12-14
.750 (19.05)
.875 (22.23)
1.188-12 UNC
5.13 (130.30)
M52525/5-16-16
1.000 (25.40)
1.000 (25.40)
1.313-12-UNC
5.50 (139.70)
M52525/5-20-20
1.250 (31.75)
1.250 (31.75)
1.625-12-UNC
4.96 (125.98)
H
N
P
Hex
inches (mm)
(see note 4)
L max
M min
PIN
+.030 (0.76)
±.005 (0.13)
size
inches (m)
inches (mm)
-.015 (0.38)
inches (mm)
inches (mm)
M52525/5-4-4
.563 (14.30)
.87 (22.10)
.300 (7.62)
.344 (8.74)
.295 (7.49)
M52525/5-4-5
.625 (15.88)
.87 (22.10)
.331 (8.41)
.375 (9.53)
.355 (9.02)
M52525/5-4-6
.688 (17.48)
.87 (22.10)
.333 (8.46)
.375 (9.53)
.435 (11.05)
M52525/5-5-6
.688 (17.48)
.98 (24.89)
.333 (8.46)
.375 (9.53)
.435 (11.05)
M52525/5-6-6
.688 (17.48)
1.09 (27.69)
.333 (8.46)
.375 (9.53)
.435 (11.05)
M52525/5-6-8
.875 (22.23)
1.09 (27.69)
.375 (9.53)
.422 (10.72)
.570 (14.48)
M52525/5-8-8
.875 (22.23)
1.20 (30.48)
.375 (9.53)
.422 (10.72)
.570 (14.48)
M52525/5-8-10
1.000 (25.40)
1.20 (30.48)
.461 (11.71)
.500 (12.70)
.680 (17.27)
M52525/5-10-12
1.250 (31.75)
1.40 (35.56)
.469 (11.91)
.562 (14.27)
.850 (21.59)
M52525/5-12-12
1.250 (31.75)
1.59 (40.39)
.469 (11.91)
.562 (14.27)
.850 (21.59)
M52525/5-12-14
1.375 (34.93)
1.59 (40.39)
.52 (13.21)
.580 (14.73)
.925 (24.50)
M52525/5-16-16
1.500 (38.10)
2.02 (51.31)
.563 (14.30)
.594 (15.09)
1.000 (25.40)
M52525/5-20-20
2.000 (50.80)
2.46 (62.48)
.563 (14.30)
.625 (15.88)
1.410 (35.81)
FIGURE 1. Fitting, screw-on to 37° flare, straight - Continued.
