MIL-DTL-52525/25B
TABLE I. Dimensions for type 100R10 fittings, 90° bent tube, short drop.
Flange
A
B
C
F
Part
Hose
Hose
A2
Flange
dash
Max
Min
Max
Max
number
size
dash
size
size
size
M52525/25-16-16
1
16
1
16
4.69
0.75
6.06
2.44
M52525/25-20-20
1-1/4
20
1-1/4
20
4.96
1.00
6.18
2.94
M52525/25-24-24
1-1/2
24
1-1/2
24
5.50
1.25
6.75
3.44
M52525/25-32-32
2
32
2
32
6.68
1.68
9.57
4.94
TABLE II. Maximum operating pressures of fittings.
Hose I.D.
PSI
1
4000
1-1/4
3000
1-12
2500
2
2500
REQUIREMENTS:
1. Fittings shall be in accordance with figure 1 and tables I and II.
2. Materials and finishes shall be as specified in MIL-DTL-52525.
3. Marking shall include the manufacturer's name or trademark, size, and hose identifier R10.
Location of marking is optional.
NOTES:
1. Dimensions are in inches.
2. Part number.
Example of a Military part number: M52525/25-16-16
-16
-16
M52525/25
Specification sheet number
Size dash number for hose (see table I)
Size dash number for flange (see table I)
2
