INCH-POUND
MIL-DTL-52525/25B
30 June 1998
SUPERSEDING
MIL-F-52525/25A
30 June 1987
DETAIL SPECIFICATION SHEET
FITTINGS, HOSE, CLAMP-ON TO 4-BOLT SPLIT-FLANGE,
90° BENT TUBE, SHORT DROP, TYPE 100R10
This specification is approved for use by all Departments and
Agencies of the department of Defense
The requirements for acquiring the product described herein shall consist of this
specification sheet and MIL-DTL-52525. The fittings described herein are for use with
MIL-DTL-52471, type 100R10, 4-spiral-wrap hose.
FIGURE 1. Fitting, clamp-on to 4-bolt split-flange, 90° bent tube, short drop.
1 of 3
AMSC N/A
FSC 4730
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
