MIL-DTL-52525/16D
Maximum operating pressure shall be as specified in table II. Maximum operating pressures are for
low carbon steel fittings consult manufacturer for values on other materials.
TABLE II. Maximum operating pressures of fittings. 1/
Working
Burst
SAE dash
pressure
PIN
pressure
size
(max)
psi
MPa
psi
MPa
-8
M52525/16-8
5000
34.5
10000
69
-12
M52525/16-12
5000
34.5
10000
69
-16
M52525/16-16
5000
34.5
10000
69
-20
M52525/16-20
4000
27.6
10000
69
-24
M52525/16-24
3000
20.7
10000
69
-32
M52525/16-32
3000
20.7
10000
69
-40
M52525/16-40
2500
17.3
7100
49
-48
M52525/16-48
2000
13.8
6000
41.4
-56
M52525/16-56
500
3.4
2000
13.8
-64
M52525/16-64
500
3.4
2000
13.8
1/ Metric equivalents are given for information only.
PIN: The PIN consists of the letter "M" the specification sheet number, a dash, a number for clamp
size, and a material finish designator.
52525/16
-12
A
M
Material/finish designator (see table I)
Size dash number for clamp-halves (see figure 1)
Specification sheet number
M prefix
PIN example: M52525/16-12A, describes a 4-bolt split-flange .750 inch (19.05 mm), aluminum with
an anodized finish.
Color identification. Color identification shall be in accordance with SAE-AS4841.
Marking shall include the manufacturer's name or trademark, size, and hose identifier R10. Location
of marking is optional.
Supersession data in table III is for reference only. SAE style fittings may not have the same
material/finish as specified in MIL-DTL-52525.
5
