MIL-DTL-25427B
TABLE VIII. Hose length and band radii for impulse test
for all pressure classes.
Hose dash
Hose OD
Hose length
Bend radii
number
Class 1000, MIL-DTL-25579 hose for 1000 psi
-04
0.250
14
2.00
-06
0.375
18
4.00
-08
0.500
21
4.63
-10
0.625
23.5
5.50
-12
0.750
27.5
6.50
-16
1.000
18
7.38
-20
1.250
18
11
-24
1.500
18
14
Class 3000 SAE-AS1339 hose for 3000 psi
-04
0.250
12
1.50
-06
0.375
15
2.50
-08
0.500
18
2.88
-10
0.625
21
3.25
-12
0.750
18
4.00
-16
1.000
23
5.00
Class 5000 MIL-H-85800 (AS) for 5000 psi
-04
0.250
12
1.50
-06
0.375
15
2.50
-08
0.500
18
2.88
-10
0.625
21
3.25
-12
0.750
25
4.00
-16
1.000
31
5.00
17
