MIL-DTL-24788A
TABLE I. Qualification test schedule.
No. 1
No. 2
No. 3
Test
Requirement
Test Method
Assembly
Assembly
Assembly
Component examination
3.3.1.1
4.4
X
X
X
Proof pressure
3.10.1
4.5.1
X
X
X
Operating force
3.10.2
4.5.2
X
X
X
Leakage
3.10.3
4.5.3
X
X
X
Semi-dry-break leakage
3.10.3.1
4.5.3.1
X
X
X
Extreme temperature
3.10.4
4.5.4
X
Total pressure loss
3.10.5
4.5.5
X
Strength
3.10.6
4.5.6
X
Angular movement
3.10.7
4.5.7
X
Endurance
3.10.8
4.5.8
X
Electrical resistance
3.10.9
4.5.9
X
Insulation breakdown
3.10.10
4.5.10
X
Accelerated corrosion
3.10.11
4.5.11
X
Rough handling
3.10.12
4.5.12
X
Burst pressure
3.10.13
4.5.13
X
Disassembly and
3.10.14
4.5.14
X
X
X
inspection
4.3 Conformance inspection. Conformance inspection shall consist of the inspections and tests as listed in
Table II.
TABLE II. Conformance inspections and tests.
Test
Requirement
Test Method
Component
3.3.1.1
4.4
examination
Proof pressure
3.10.1
4.5.1
Electrical resistance
3.10.9
4.5.9
Insulation breakdown 1/
3.10.10
4.5.10
NOTE:
1/
Class 2 couplings
4.3.1 Sampling for conformance inspection. As a minimum, the contractor shall randomly select a sample
quantity of completed and test subjected semi-dry-break, quick-disconnect coupling assemblies, male and/or female
halves, in accordance with Table III and examine them in accordance with Table II.
8
