MIL-C-52705B
TABLE I. Type code letter.
Code number
Type
A
A
B
B
C
C
Type A - Expansion ring coupling with slotted swivel.
Type B - Ribbed shank coupling with hexagonal swivel.
Type C - Ribbed shank coupling with wing nut swivel.
6.4.2 Size. The size of the coupling is identified by a single digit number (see table II).
TABLE II Nominal size code number.
Code number
Nominal size (in inches)
1
1/2 (.50)
2
3/4 (.75)
3
1
(1.00)
4
1-1/4 (1.25)
5
1-1/2 (1.50)
6
2
(2.00)
7
2-1/2 (2.50)
6.4.3 Finish. Finish for the type C coupling shall be identified by a single alphabetic letter
(see table III).
9
