AN914 Rev 11
A
B
D (drill depth)
E (drill depth)
Dash
+.047 (1.19)
C
+.047 (1.19)
+.047 (1.19)
Pipe thread
SAE-AS5201
number
-0.00
inches (mm)
-0.00
-0.00
ANPT
size code
inches (mm)
inches (mm)
inches (mm)
SAE-AS71051
1
1/8-27
02
.609 (15.47)
.625 (15.88)
.641 (16.28)
.891 (22.63)
2
1/4-18
04
.891 (22.63)
.813 (20.65)
.938 (23.83)
1.266 (32.16)
3
3/8-18
06
.938 (23.83)
.938 (23.83)
1.000 (25.40)
1.359 (34.52)
4
1/2-14
08
1.172 (29.77)
1.188 (30.18)
1.297 (32.94)
1.734 (44.04)
6
3/4-14
12
1.344 (34.14)
1.375 (34.93)
1.469 (37.31)
1.859 (47.22)
8
1-11 1/2
16
1.594 (40.49)
1.750 (44.45)
1.719 (43.66)
2.234 (56.74)
10
1/ 1/4-11 1/2
20
1.750 (44.45)
2.156 (57.76)
1.906 (48.41)
2.375 (60.33)
M
P
S
U
K
+.047 (1.19)
Dash
F (drill depth)
Dia.
Approx
Approx
Dia.
-0.00
number
inches (mm)
inches (mm)
inches (mm)
inches (mm)
inches (mm)
inches (mm)
1
.422 (10.72)
.188 (4.78)
.859 (21.82)
.578 (14.68)
.500 (12.70)
.250 (6.35)
2
.563 (14.30)
.281 (7.14)
1.219 (30.96)
.781 (19.84)
.625 (15.88)
.375 (9.53)
3
.609 (15.47)
.406 (10.31)
1.297 (32.94)
.922 (23.42)
.750 (19.05)
.500 (12.70)
4
.797 (20.24)
.531 (13.49)
1.609 (40.87)
1.156 (29.36)
.875 (22.23)
.625 (15.88)
6
.813 (20.65)
.719 (18.26)
1.734 (44.04)
1.359 (34.52)
1.000 (25.40)
.750 (19.05)
8
.969 (24.61)
.938 (23.83)
2.109 (53.57)
1.688 (42.88)
1.125 (28.58)
.875 (22.23)
10
.969 (24.61)
1.125 (28.58)
2.250 (57.15)
2.063 (52.40)
1.250 (31.75)
1.000 (25.40)
V
W
Weight max lbs (kg)
Dash
Rad.
Rad.
number
Copper alloy
Al alloy
Steel, CRES
Ti alloy
inches (mm)
inches (mm)
1
.219 (5.56)
.063 (1.60)
.069 (0.03)
.023 (0.010)
.069 (0.031)
.038 (0.017)
2
.281 (7.14)
.094 (2.39)
.180 (0.08)
.060 (0.027)
.180 (0.082)
.100 (0.045)
3
.344 (8.74)
.094 (2.39)
.240 (0.11)
.080 (0.036)
.240 (0.109)
.132 (0.060)
4
.438 (11.13)
.125 (3.18)
.435 (0.20)
.145 (0.066)
.434 (0.197)
.240 (0.109)
6
.574 (14.58)
.125 (3.18)
.600 (0.27)
.200 (0.091)
.599 (0.272)
.331 (0.150)
8
.688 (17.48)
.125 (3.18)
1.140 (0.52)
.380 (0.172)
1.138 (0.516)
.628 (0.285)
10
.859 (21.82)
.156 (3.96)
1.720 (0.78)
.580 (0.263)
1.737 (0.788)
.959 (0.435)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified tolerances are ±.016 inch (0.41 mm).
4. Break sharp edges .and remove all hanging burrs and slivers
5. Machined surfaces shall be finished to 125µin Ra, forged surfaces shall be 250µin Ra, unless otherwise
specified on the figures. Surface finish shall be in accordance with ASME B46.1.
6. For design features purposes, this standard takes precedence over documents referenced herein.
7. Referenced documents shall be of the issue in effect on date of invitation for bid.
FIGURE 1. Elbow 90° dimensions and configuration - Continued.
