INCH-POUND
AN914 Rev 11
12 December 2012
SUPERSEDING
AN914 Rev 10
19 July 2011
DETAIL SPECIFICATION SHEET
ELBOW, PIPE, INTERNAL AND EXTERNAL THREAD, 90°
Reinstated after 19 July 2011. Inactive for new design.
For new design, use SAE-AS4854.
This specification is approved for use by all Departments and
Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
SAE-AS4842.
FIGURE 1. Elbow 90° dimensions and configuration.
AMSC N/A
FSC 4730
