AN844 Rev 13
B
A
Dash
Hose ID
+.047 (1.19)
C
Pipe thread
number
inches (mm)
-.000
inches (mm)
SAE-AS71051
inches (mm)
4
.250 (6.35)
1/8-27 ANPT
.625 (15.88)
.438 (11.13)
6
.375 (9.53)
1/4-18 ANPT
.875 (22.23)
.625 (15.88)
8
.500 (12.70)
3/8-18 ANPT
.922 (23.42)
.750 (19.05)
10
.625 (15.88)
1/2-14 ANPT
1.156 (29.36)
.938 (23.83)
12
.750 (19.05)
3/4-14 ANPT
1.203 (30.56)
1.125 (28.58)
16
1.000 (25.40)
3/4-14 ANPT
1.203 (30.56)
1.125 (28.58)
17
1.000 (25.40)
1-11.5 ANPT
1.484 (37.69)
1.375 (34.93)
20
1.250 (31.75)
1/ 1/4-11.5 ANPT
1.500 (38.10)
1.750 (44.45)
21
1.250 (31.75)
1 -11.5 ANPT
1.484 (37.69)
1.375 (34.93)
24
1.500 (38.10)
1 1/2-11.5 ANPT
1.563 (39.70)
2.000 (50.80)
25
1.500 (38.10)
1 1/4-11.5 ANPT
1.438 (37.67)
1.750 (44.45)
M
Dash
J dia.
+.047 (1.19)
S approx
U approx
number
inches (mm)
-.000
inches (mm)
inches (mm)
inches (mm)
4
.438 (11.13)
1.625 (41.28)
.313 (7.95)
.219 (5.56)
6
.578 (14.68)
1.688 (42.88)
.375 (9.53)
.281 (7.14)
8
.719 (18.26)
1.719 (43.66)
.500 (12.70)
.313 (7.95)
10
.891 (22.63)
1.781 (45.24)
.625 (15.88)
.375 (9.53)
12
1.094 (48.36)
1.813 (46.05)
.625 (15.88)
.438 (11.13)
16
1.094 (48.36)
1.813 (46.05)
.625 (15.88)
.438 (11.13)
17
1.375 (34.93)
1.875 (47.63)
.750 (19.05)
.563 (14.30)
20
1.719 (43.66)
1.938 (49.23)
.938 (23.83)
.563 (14.30)
21
1.375 (34.93)
1.875 (47.63)
.750 (19.05)
.563 (14.30)
24
1.953 (49.61)
2.000 (50.80)
1.125 (28.58)
.625 (15.88)
25
1.719 (43.66)
2.000 (50.80)
1.125 (28.58)
.625 (15.88)
FIGURE 1. 45° elbow dimensions and configuration - Continued.
