INCH-POUND
AN844 Rev 13
3 October 2013
SUPERSEDING
AN844 Rev 12
7 June 2011
DETAIL SPECIFICATION SHEET
ELBOW - PIPE TO HOSE, 45°
Reinstated after 7 June 2011. Inactive for new design
after 7 June 2011. For new design, use SAE-AS5186.
This specification is approved for use by all Departments and
Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
SAE-AS4843/2.
FIGURE 1. 45° elbow dimensions and configuration.
AMSC N/A
FSC 4730
