AN774 Rev 8
A Dia.
Thread T
B
C
Dash
Tubing OD
+.000
(Ref)
±.010 (0.25)
±.015 (0.38)
number
inches (mm)
-.004 (0.10)
SAE-AS8879
inches (mm)
inches (mm)
inches (mm)
-4
.250 (6.35)
.4375-20UNJF-3A
.435 (11.05)
.781 (19.84)
.438 (11.13)
-5
.313 (7.95)
.5000-20UNJF-3A
.498 (12.65)
.781 (19.84)
.438 (11.13)
-6
.375 (9.53)
.5625-18UNJF-3A
.560 (14.22)
.875 (22.23)
.469 (11.91)
-8
.500 (12.70)
.750-16UNJF-3A
.748 (19.00)
1.094 (27.79)
.563 (14.30)
-10
.625 (15.88)
.8750-14UNJF-3A
.873 (22.17)
1.250 (31.75)
.594 (15.09)
-12
.750 (19.05)
1.0625-12UNJ-3A
1.060 (26.92)
1.468 (37.29)
.656 (16.66)
-16
1.000 (25.40)
1.3125-12UNJ-3A
1.310 (33.27)
1.687 (42.85)
.656 (16.66)
F Dia.
G Hex
D
+010 (0.25)
E
L Dia.
Dash
(ref)
±.015 (0.38)
-.000
±.015 (.038)
.015 (0.38)
number
(see note 5)
inches (mm)
(see note 7)
inches (mm)
inches (mm)
inches (mm)
inches (mm)
-4
1.188 (30.18)
1.922 (48.82)
.469 (11.91)
.688 (17.48)
.344 (8.74)
-5
1.188 (30.18)
1.922 (48.82)
.531 (13.49)
.750 (19.05)
.406 (10.31)
-6
1.344 (34.14)
2.125 (53.98)
.594 (15.09)
.813 (20.65)
.469 (11.91)
-8
1.688 (42.88)
2.594 (65.89)
.781 (19.84)
1.000 (25.40)
.625 (15.88)
-10
1.969(50.01)
3.000 (76.20)
.906 (23.01)
1.125 (28.58)
.750 (19.05)
-12
2.313 (58.75)
3.484 (88.49)
1.094 (27.79)
1.375 (34.93)
.938 (23.83)
-16
2.813 (71.45)
4.094 (103.99)
1.344 (34.14)
1.625 (41.28)
1.188 (30.18)
FIGURE 1. Bolt - flared tube dimensions and configurations - Continued.
