AN763 Rev 2
Inches
mm
.005
0.13
.016
0.41
G
Nominal tube
Dash
A dia.
D dia
E dia
+.010
and hose size
number
inch (mm)
inch (mm)
inch (mm)
-.005
inches (mm)
inch (mm)
-56
3.500 (88.90)
3.375 (85.73)
4.875 (123.83)
5.562 (141.27)
-64
4.000 (101.60)
3.875 (98.43)
5.438 (138.13)
6.125 (155.58)
-80
5.000 (127.00)
4.875 (123.83)
6.438 (163.53)
7.125 (180.98)
.328 (8.33)
-96
6.000 (152.40)
5.875 (149.23)
7.438 (188.93)
8.125 (206.38)
-112
7.000 (177.80)
6.875 (174.63)
8.500 (215.90)
9.188 (233.38)
H
Dash
number
number
of holes
-56
8
-64
8
-80
10
-96
12
-112
14
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified tolerances are ±.010 inch (0.25 mm), angles ±2°.
4. Thickness tolerance as specified in the material specifications.
FIGURE 3. Gasket sizes -56 through -112.
4
