AN763 Rev 2
Inches
mm
.005
0.13
.016
0.41
Nominal tube
B
Dash
A dia.
C
D dia
and hose size
±.005
number
inch (mm)
inch (mm)
inch (mm)
inches (mm)
inch (mm)
-40
2.500 (63.50)
2.375 (60.33)
---
4.000 (101.60)
3.812 (96.82)
-48
3.000 (76.20)
2.875 (73.03)
---
4.500 (114.30)
4.312 (109.52)
G
Dash
E dia
F rad
+.010
number
inch (mm)
inch (mm)
-.005
inch (mm)
-40
4.500 (114.30)
.375 (9.53)
.328 (8.33)
-48
5.000 (127.00)
.625 (15.88)
.328 (8.33)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified tolerances are ±.010 inch (0.25 mm), angles ±2°.
4. Thickness tolerance as specified in the material specifications.
FIGURE 2. Gasket sizes -40 through -48.
3
