MIL-PRF-20042E
TABLE V.
Classification of defects.
Categories
Defects
None defined.
Critical
Major:
Type, class, size and rating not as specified.
101
Material not as specified.
102
Flanges not sound, smoothly corded, true to form, uniform in
103
texture, not free from cold shuts and porosity.
Flanges surface (internal and external) not thoroughly cleaned,
104
fins and roughness not removed.
Brazing ring (if specified) missing or not as specified.
105
Socket not smooth.
106
Socket dimensions not as specified.
107
Flange dimensions not within tolerance specified.
108
Minor:
Ends (other than preinserted ring type) not chamfered as
201
specified.
Marking not cast, or stamped incorrect, or illegible.
202
4.3
Test methods.
4.3.1 Hydrostatic pressure leakage test. Each sample flange selected
as specified in 4.1.3 shall be subjected to a hydrostatic pressure 1-1/2 times
the rated pressure for 1 minute. Under the hydrostatic pressure, the fitting
shall not leak water or sweat at any part of the surface.
4.3.2 Air pressure leakage test. Each flange shall be tested under
water or with soapsuds at 100 pounds per square inch (lb/in2) (nominal) air
pressure (85 lb/in2 minimum) for 5 to 10 seconds. No leakage is allowed.
4.3.3 Chemical analysis. Each sample flange selected as specified in
4.1.4 for chemical analysis shall be tested in accordance with ASTM E172 or
ASTM E1282 to determine conformance to 3.1.
5.
PACKAGING
5.1 Packaging. For acquisition purposes, the packaging requirements
shall be as specified in the contract or order (see 6.2). When actual
packaging of material is to be performed by DoD personnel, these personnel
need to contact the responsible packaging activity to ascertain requisite
packaging requirements. Packaging requirements are maintained by the
Inventory Control Point's packaging activity within the Military Department or
Defense Agency, or within the Military Department's System Command. Packaging
data retrieval is available from the managing military Department's or Defense
Agency's automated packaging files, CD-ROM products, or by contacting the
responsible packaging activity.
