MIL-DTL-83798/7C
A
Weight
Dash
(max)
(max)
Number
inch
mm
lbs.
grams
-8
1.82 46.23
0.099 44.91
-10
1.87 47.50
0.122 55.34
-12
2.29 58.17
0.165 74.84
-16
2.60 66.04
0.251 113.85
-20
2.82 71.63
0.368 166.92
-24
2.74 69.60
0.454 205.93
-32
3.08 78.23
0.739 335.20
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
FIGURE 1. Fitting, swivel flange straight - Continued.
REQUIREMENTS:
Design and construction:
Dimensions and configuration: See figure 1.
Materials and finishes. Materials and finishes for the flange, nipple, and socket shall be as
specified in table I.
The swivel flange shall be in accordance with MS20756 and shall mate with MS33786.
TABLE I. Material and finish.
Component
Material
Finish
Socket
Aluminum in accordance with
Anodize in accordance with MIL-A-8625,
Nipple
MIL-DTL-83798
type II.
Flange
Titanium in accordance with
Annealed
All
SAE-AMS4928 (alloy 6AI-4V)
