MIL-DTL-83798/4C
Nut and nipple material and finish code for steel (sizes -3, -4, and -5)are specified in table I.
TABLE I. Nut and nipple material and finish code. 1/
PIN code
Material
Plating Finish
dash letter
Cadmium plating in accordance with
Steel (sizes -3, -4, and -5)
SAE-AMS-C-81562, type II, class 3 or
Blank
SAE-AMS-QQ-P-416, type II, class 2.
Aluminum (sizes -6 and above) Anodize in accordance with MIL-A-8625, type II.
Aluminum-nickel in accordance with ASTM F1136,
-A
Steel (sizes -3, -4, and -5)
grade 3, NC.
Anodize in accordance with MIL-A-8625, type II with
Naval Air Systems Command (NAVAIR) trivalent
-B
Aluminum (sizes -6 and above)
chromium pretreatment (TCP) in accordance with
MIL-DTL-81706, type 2, class A.
Cadmium plating in accordance with
SAE-AMS-C-81562, type II, class 3 or
-CN
Steel (sizes -3, -4, and -5)
SAE-AMS-QQ-P-416, type II, class 2 with NAVAIR
TCP in accordance with MIL-DTL-81706, type 2, class
A.
Zinc phosphate finish in accordance MIL-DTL-16232
-H
Steel (sizes -3, -4, and -5)
type Z, class1. 2/
Zinc plating in accordance with ASTM B633; type II or
-J
Steel (sizes -3, -4, and -5)
III, Fe/Zn 5, or ASTM B695, type II, class 5.
NAVAIR TCP in accordance with MIL-DTL-81706, type
N
Steel (sizes -3, -4, and -5)
2, class A.
Zinc plating in accordance with ASTM B633; type VI,
-R
Steel (sizes -3, -4, and -5)
Fe/Zn 5.
Corrosion resistant steel
No additional finish. Passivation in accordance with
-S
(sizes -3, -4, and -5)
SAE-AMS2700, method 2.
-T
Titanium (all sizes)
Annealed
-V
Steel (sizes -3, -4, and -5)
Zinc-nickel in accordance with SAE-AMS2417, type 1.
-Z
Steel (sizes -3, -4, and -5)
Zinc any type above PIN code F, G, H, J, K, R, V
Zinc any type above PIN code F, G, H, J, K, R, V with
-ZN
Steel (sizes -3, -4, and -5)
trivalent chromium pretreatment (TCP) in accordance
with MIL-DTL-81706, type 2, class A.
1/ Shall be capable of withstanding minimum of 96 hours salt spray.
2/ Hexavalent chromium free.
Guidance on use of alternative parts with less hazardous or nonhazardous materials. This
specification provides for a number of alternative plating materials via the PIN. Users should select
the PIN with the least hazardous material that meets the form, fit and function requirements of their
application.
