INCH-POUND
MIL-DTL-52618/2E
26 January 2012
SUPERSEDING
MIL-DTL-52618/2D
25 November 2002
DETAIL SPECIFICATION SHEET
FITTINGS, PIPE, ALUMINUM-ALLOY THREADED, 150-POUND,
REDUCERS AND CLOSE AND OPEN PATTERN RETURN BENDS (STRAIGHT SIZES)
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-52618.
FIGURE 1. Reducer, closed and open return bend.
Requirements
The fittings shall be as specified on figure 1.
Intended use is with water, oil, or air 150 psi (1.03 MPa) max at 72°F (22°C).
The design, dimensions, and tolerances of reducers and bends shall be in accordance with
AMSE B16.3.
Aluminum shall be in accordance with MIL-DTL-52618.
AMSC N/A
FSC 4730
