MIL-DTL-52525/2C
To the users of this document, it is recommended that the use of carbon steel material with cadmium
plating be used only when the other materials and finishes specified in this document cannot meet
performance requirements.
Color identification. Color identification shall be in accordance with SAE-AS4841.
Marking shall include the manufacturer's name or trademark, size, and hose identifier R2. Location of
marking is optional.
Harmonization to SAE-J516 cross reference PIN in table IV is for reference only. SAE style fittings may not
have the same material/finish as required by MIL-DTL-52525 and legacy with
MIL-DTL-52471.
TABLE IV. Harmonization to SAE-J516 cross reference PIN. 1/
PIN
SAE PIN
M52525/2-4-4
SAE J516 4-4 F242254
M52525/2-4-5
SAE J516 5-4 F242254
M52525/2-6-6
SAE J516 6-6 F242254
M52525/2-8-8
SAE J516 8-8 F242254
M52525/2-8-10
SAE J516 10-8 F242254
M52525/2-12-12
SAE J516 12-12 F242254
M52525/2-16-16
SAE J516 16-16 F242254
1/ Material and finish designators are omitted from
PIN's, see table I and SAE-J846.
Changes from previous issue. Marginal notations are not used in this revision to identify changes with
respect to the previous issue, due to the extent of the changes.
Referenced documents. In addition to MIL-DTL-52525, this document references the following:
ASTM B633
SAE-AMS2700
MIL-A-8625
ASTM B695
SAE-AS4841
MIL-DTL-16232
ASTM F1136
SAE-J516
MIL-DTL-52471
SAE-AMS-C-81562
SAE-J517
MIL-DTL-52471/2
SAE-AMS-QQ-P-416
SAE-J846
MIL-DTL-52471/5
SAE-AMS2417
MIL-DTL-81706
ASME B1.1
SAE-AMS2488
