MIL-DTL-52525/15C
A
B
C
D
PIN
inches (mm)
inches (mm)
inches (mm)
inches (mm)
M52525/15-12-12
5.28 (134.11)
2.06 (52.32)
1.625 (41.28)
1.94 (49.28)
M52525/15-16-16
5.84 (148.34)
2.38 (60.45)
2.000 (50.80)
2.03 (51.56)
M52525/15-20-20
7.86 (199.64)
2.62 (66.55)
2.625 (66.68)
3.00 (76.20)
M52525/15-24-24
8.85 (224.79)
3.13 (79.50)
2.875 (73.03)
2.87 (72.90)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. All dimensions not shown shall be in accordance with SAE-J516 and SAE-J518 as applicable.
4. Formerly SAE-J517, type 100R10 hose.
FIGURE 1. Fitting, screw-on to 4-bolt split-flange, 90° bent tube - Continued
ENGINEERING DATA:
Note: SAE-J517, type 100R10 hoses have been discontinued by SAE. Use SAE-J517 hoses
specified in table I. The "RE" designator at the end of the hose type "100RE" is a MIL-DTL-52471
term used to indicate a hose type that has been discontinued and to use an SAE-J517 replacement
hose.
TABLE I. Hose type 100R10 to SAE replacement. 1/
100R10
Operating
SAE-J517
SAE
100RE
hose
pressure
replacement
MPa
MPa
dash size
psi
-12
SAE J517 100R13-12
5000
35
34.5
-16
SAE J517 100R13-16
4000
35
27.6
-20
SAE J517 100R12-20
3000
21
20.7
-24
SAE J517 100R12-24
2500
17.5
17.2
1/ If the SAE-J517 hose in table I does not meet system requirements
chose an SAE-J517 hose with pressure requirements at or above
pressure requirements specified in this specification.
REQUIREMENTS:
The fittings described herein are for use with hose in accordance with SAE-J517 and hose
assemblies in accordance with MIL-DTL-52471/3.
Fittings shall be as specified on figure 1 and in tables II and III.
If fittings are to be used on an oxygen hose, see MIL-DTL-52525.
Materials and finishes shall be in accordance with MIL-DTL-52525 and in table II. All finishes shall be
capable of withstanding 96 hours minimum of salt spray.
2
