MIL-DTL-52525/14C
C
F
PIN
inches (mm)
inches (mm)
M52525/14-12-12
1.625 (41.28)
1.00 (25.40)
M52525/14-16-16
2.000 (50.80)
1.06 (26.92)
M52525/14-20-20
2.625 (66.68)
1.19 (30.23)
M52525/14-24-24
2.875 (73.03)
1.44 (36.58)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. All dimensions not shown shall be in accordance with SAE-J516 and SAE-J518 as applicable.
4. SAE-J516 type, for use with SAE-J517, type 100RE hose (formerly SAE-J517, type 100R10 hose),
coupled to part using SAE-J518 split-flange type.
FIGURE 1. Fitting, screw-on to 4-bolt split-flange, 45° bent tube - Continued.
ENGINEERING DATA:
SAE-J517, type 100R10 hoses have been discontinued by SAE. Use SAE-J517 hoses specified in
table I. The "RE" designator at the end of the hose type "100RE" is a MIL-DTL-52471 term used to
indicate a hose type that has been discontinued and to use an SAE-J517 replacement hose.
TABLE I. Hose type 100RE to SAE replacement. 1/
Operating
100R10
SAE
100RE
SAE-J517
pressure
hose
MPa
MPa
replacement
psi
dash size
-12
SAE J517 100R13-12
5000
35
34.5
-16
SAE J517 100R13-16
4000
35
27.6
-20
SAE J517 100R12-20
3000
21
20.7
-24
SAE J517 100R12-24
2500
17.5
17.2
1/ If the SAE-J517 hose does not meet system requirements chose
an SAE-J517 hose with pressure requirements at or above
pressure requirements specified in this specification.
REQUIREMENTS:
The fittings described herein are for use with hose in accordance with SAE-J517 and hose
assemblies in accordance with MIL-DTL-52471/3.
Fittings shall be as specified on figure 1 and in tables II, III, and IV.
If fittings are to be used on an oxygen hose see MIL-DTL-52525.
Materials and finishes shall be in accordance with MIL-DTL-52525 and in table II. All finishes shall be
capable of withstanding 96 hours minimum of salt spray.
2
