INCH-POUND
MIL-DTL-52525/13C
20 November 2008
SUPERSEDING
MIL-DTL-52525/13B
30 June 1998
DETAIL SPECIFICATION SHEET
FITTINGS, HOSE, CRIMP TYPE,
SPLIT-FLANGE STRAIGHT
This specification is approved for use by all Departments and
Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet
and MIL-DTL-52525.
Flange
Hose
head
Tube
A
B
C
Part or Identifying
dash
inches
inches
inches
ID ref
Size
Number (PIN)
Dash
Dash
no.
(mm)
(mm)
(mm)
inches
inches
no.
no.
(mm)
(mm)
.750
5.28
1.94
1.625
.750
-12
-12
M52525/13-12-12
-12
(19.05)
(134.11)
(49.28)
(41.28)
(19.05)
1.000
5.53
2.03
2.000
1.000
-16
-16
M52525/13-16-16
-16
(25.40)
(140.46)
(51.56)
(50.80)
(25.40)
1.250
7.34
3.00
2.6258
1.250
-20
-20
M52525/13-20-20
-20
(31.75)
(186.44)
(76.20)
(66.70)
(31.75)
1.500
1.500
7.75
2.87
2.875
M52525/13-24-24
-24
-24
-24
(38.10)
(38.10)
(196.85)
(72.90)
(73.03)
FIGURE 1. Fitting, screw-on to 4-bolt split-flange, straight.
AMSC N/A
FSC 4730
