MIL-DTL-52525/11C
D
B
C max
inches (mm)
PIN
inches (mm)
inches (mm)
.12 (3.0)
M52525/11-8-8
1.27 (32.26)
1.38 (35.05)
.78 (19.81)
M52525/11-12-12
1.36 (34.54)
1.75 (44.45)
1.00 (25.40)
M52525/11-16-16
1.61 (40.89)
1.75 (44.45)
1.06 (26.92)
M52525/11-16-20
1.61 (40.89)
2.06 (52.32)
1.09 (27.69)
M52525/11-20-20
1.80 (45.72)
2.63 (66.80)
1.15 (29.21)
M52525/11-24-24
2.08 (52.83)
2.94 (74.68)
1.41 (1041.40)
M52525/11-32-32
2.44 (61.98)
3.50 (88.90)
2.00 (50.80)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. All dimensions not shown shall be in accordance with SAE-J516 and SAE-J518 as applicable.
4. SAE-J516 fittings assembled with SAE-J517 hose and SAE-J518 flange to manufacturer
MIL-DTL-52471 hose assembly.
FIGURE 1. Fitting, screw-on to 4-bolt split-flange, 45 bent tube - Continued.
REQUIREMENTS:
Fittings shall be as specified on figure 1 and in tables I, II, and III.
The fittings described herein are for use with MIL-DTL-52471/5, type 100R2, double wire braided
hose and hose assemblies in accordance with MIL-DTL-52525/2.
If fittings are to be used on an oxygen hose, see MIL-DTL-52525.
Materials and finishes shall be as specified on MIL-DTL-52525 and in table I. All finishes shall be
capable of withstanding 96 hours minimum of salt spray.
2
