MIL-DTL-52525/10D
Flange
Hose
head
Tube
A max
B min
C max
Part or Identifying
dash
inches
inches
inches
Hose
ID
Number (PIN)
Dash
inches
no.
(mm)
(mm)
(mm)
dash
inches
no.
(mm)
no.
(mm)
.500
.500
3.78
1.27
1.38
M52525/10-8-8
-8
-8
-8
(12.70)
(12.70)
(96.01)
(32.26)
(35.05)
.500
.750
4.02
1.32
1.57
M52525/10-8-12
-8
-12
-12
(12.70)
(19.05)
(102.11)
(33.53)
(39.88)
.750
4.14
1.34
1.66
M52525/10-10-12
-10
.625 (
-12
-12
(19.05)
(105.16)
(34.04)
(42.16)
.750
.750
4.25
1.36
1.75
M52525/10-12-12
-12
-12
-12
(19.05)
(19.05)
(107.95)
(34.54)
(44.45)
.750
1.000
4.50
1.49
1.91
M52525/10-12-16
-12
-16
-16
(19.05)
(25.40)
(111.43)
(33.53)
(48.51)
1.000
1.000
4.74
1.61
2.06
M52525/10-16-16
-16
-16
-16
(25.40)
(25.40)
(120.40)
(40.89)
(52.32)
1.000
1.250
4.74
1.61
2.06
M52525/10-16-20
-16
-20
-20
(25.40)
(31.75)
(120.40)
(40.89)
(52.32)
1.250
1.250
5.35
1.80
2.63
M52525/10-20-20
-20
-20
-20
(31.75)
(31.75)
(135.89)
(45.72)
(66.80)
1.250
1.500
5.35
1.80
2.63
M52525/10-20-24
-20
-24
-24
(31.75)
(38.10)
(135.89)
(45.72)
(66.80)
1.500
1.500
5.61
2.08
2.94
M52525/10-24-24
-24
-24
-24
(38.10)
(38.10)
(142.49)
(52.83)
(74.68)
1.500
2.000
5.61
2.08
2.94
M52525/10-24-32
-24
-32
-32
(38.10)
(50.80)
(142.49)
(52.83)
(74.68)
2.000
2.000
6.37
2.44
3.50
M52525/10-32-32
-32
-32
-32
(50.80)
(50.80)
(161.80)
(61.98)
(88.90)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. All dimensions not shown shall be in accordance with SAE-J516 and SAE-J518 as applicable.
4. These fittings are similar to SAE-J516 assemble with SAE-J517 hose and SAE-J518 flange to
manufacturer MIL-DTL-52471 hose assembly.
FIGURE 1. Fitting, screw-on to 4-bolt split-flange, straight - Continued.
REQUIREMENTS:
Fittings shall be as specified in figure 1 and in tables I and II.
The fittings described herein are for use with MIL-DTL-52471/5, type 100R2, double wire braided
hose and hose assemblies in accordance with MIL-DTL-52525/2.
If fittings are to be used on an oxygen hose, see MIL-DTL-52525.
Materials and finishes shall be in accordance with MIL-DTL-52525 and in table I. All finishes shall be
capable of withstanding 96 hours minimum of salt spray.
