MIL-DTL-17813H
1.3 Part or Identifying Number (PIN). The PIN to be used for metallic bellows, expansion joint pipes
acquired to this specification are created as follows:
M
17813 /1 - 3 - I - 1 - 150 - W
End connection (F for flange ends, W for weld
ends, and V for Vanstone ends)
Pressure rating
Class
Type
Size
Specification sheet number
Specification number
M prefix
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this
specification. This section does not include documents cited in other sections of this specification or
recommended for additional information or as examples. While every effort had been made to ensure the
completeness of the list, document users are cautioned that they must meet all specified requirements
documents cited in sections 3, 4, or 5 of this specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and
handbooks form a part of this document to the extent specified herein. Unless otherwise specified, the
issues of these documents are those listed in the solicitation or contract.
DEPARTMENT OF DEFENSE SPECIFICATIONS
(See supplement 1 for list of specification sheets.)
2.3 Non-Government publications. The following documents form a part of this document to the
extent specified herein. Unless otherwise specified, the issues of these documents are cited in the
solicitation or contract.
AMERICAN SOCIETY OF MECHANICAL ENGINEERS (ASME)
ASME B16.5
-
Steel Pipe Flanges and Flanged Fittings
ASME B31.1
-
Piping, Power
ASME
-
ASME Boiler and Pressure Vessel Code
(Copies of these documents are available online at https://www.asme.org or from the ASME Information
Central Orders/Inquiries, P.O. Box 2300, Fairfield, NJ 07007-2300.)
2
