INCH-POUND
GGG-C-2794A
29 March 2013
SUPERSEDING
GGG-C-2794
10 April 1992
FEDERAL SPECIFICATION
CUPS, OIL, LUBRICATING, AND OILERS, SELF-FEEDING, GENERAL SPECIFICATION FOR
Inactive for new design after 29 December 2000.
This General Services Administration has authorized the use of this federal
specification, by all federal agencies.
1. SCOPE AND CLASSIFICATION
1.1 Scope. This specification covers oil cups used for lubricating wearing parts of mechanical
equipment.
1.2 Classification.
1.2.1 Types and styles. Oil cups are of the following types and styles, as applicable, as specified (see
6.2 and 6.5):
Type A
Screw cap (see GGG-C-2794/1)
Type B
Spring cap (see GGG-C-2794/2)
Type C
Cylindrical slotted cap (see GGG-C-2794/3)
Type D
Hinged cap (see GGG-C-2794/4)
Type F
With sight feed (see GGG-C-2794/5)
Type G
Ball valve (drive), straight (see GGG-C-2794/6)
Style 1 With flange
Style 2 Without flange
Type H
Small elbow (see GGG-C-2794/7)
1.3 Part or Identifying Number (PIN). The PIN consists of the specification identifier (GGGC2794), the
classification type and style (see 1.2), and from the applicable table (see specification sheet), the size
code number, the body material code, and the transparent material code (reservoir and sight window).
GGGC2794 - G1 - 02 - BZ - PC
Transparent material code
Material
Size code
Type and/or style (see 1.2.1)
Specification number
Comments, suggestions, or questions on this document should be addressed to: DLA Land and Maritime,
Attn: VAI, P.O. Box 3990, Columbus, Ohio, 43218-3990 or emailed to FluidFlow@dla.mil. Since contact
information can change, you may want to verify the currency of this address information using ASSIST
Online Database at https://assist.dla.mil.
AMSC N/A
FSC 4730
