INCH-POUND
AND10089, REV 7
18 October, 1999
SUPERSEDING
AND10089 REV 6
24 February 1994
DETAIL SPECIFICATION SHEET
FITTING END, DESIGN STANDARD, FOR CONE CONNECTION
This specification is approved for use by all Departments and
Agencies of the Department of Defense.
D
63
THREAD T
.004 A
C
A
ØA
ØB
CHAMFER 45°
STYLE G
63
DRILL J
E
THREAD RELIEF 1.5
CSINK 100° x H
THREAD TO ROOT Ø
C
F
+.000
R .031 -.016
ØB
ØA
Q
L
SHOULDER
HEX OR BODY
30° ± 5° TO
STYLE E
THREAD T
Ø F OF
HEX
THIS SURFACE SHALL BE FREE FROM BURRS,
LONGITUDINAL AND SPIRAL TOOL MARKS, AND
SHALL BE SMOOTH, EXCEPT THAT ANNULAR TOOL
CHAMFER 45°
MARKS WILL BE ALLOWED TO 100 IN. Ra MAX.
COMPLETE THREAD
TO THIS POINT
K
FIGURE 1. Fitting end
1 of 3
AMSC N/A
FSC 4730
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited
