INCH-POUND
AN848 Rev 12
7 June 2011
SUPERSEDING
AN848 Rev 11
20 March 1979
DETAIL SPECIFICATION SHEET
ELBOW, HOSE, 90°
Reinstated after 7 June 2011. Inactive for new design.
For new design, use SAE-AS5188.
This specification is approved for use by all Departments and
Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
SAE-AS4843.
Inch
mm
.01325
0.80
FIGURE 1. 90° elbow dimensions and configuration.
AMSC N/A
FSC 4730
