AN800 Rev 6
REQUIREMENTS
Dimensions. See table I. Unless otherwise specified tolerances on decimals are ±.010, angles ±0.5°.
Configuration. See figure 1. Surfaces "S" must run true with each other within .002 full indicator measurement.
Inactive for new design. Dash numbers 12 and 16 are inactive for new design.
Dash numbers 2, 3 and 4 are inactive for new design except for use in oxygen systems and engine primer lines.
Dash numbers 5, 6, 8 and 10 are inactive for new design and are not to be used on engine primer lines.
Materials:
Brass; bars, shapes or forgings.
Corrosion resistant steel; bars, shapes or forgings.
Nickel copper alloy; bars, shapes or forgings.
See procurement specification.
Finish:
See procurement specification.
Identification of product. Add P before the dash number for cadmium plated brass cones and for cadmium plated
nickel copper alloy cones.
AN800 X X
Size
Material, finish
Drawing number
Example of Part or Identifying Number (PIN):
AN800-2 cone union, brass, for .125 tubing OD.
AN800P2 cone union, brass, cadmium plated, for .125 tubing OD.
AN800C2 cone union, corrosion resistant steel, for .125 tubing OD.
AN800N2 cone union, nickel copper alloy, for .125 tubing OD.
AN800PC2 cone union, nickel copper alloy, cadmium plated, for .125 tubing OD.
Workmanship. Break all sharp edges and remove all hanging burrs and slivers which might become dislodged under
usage.
Changes from previous issue. Marginal notations are not used in this revision to identify changes with respect to the
previous issue due to the extent of the changes.
Referenced documents. This document references MIL-DTL-6001.
CONCLUDING MATERIAL
Custodians:
Preparing activity:
Army AR
DLA - CC
Navy SH
Air Force - 99
DLA - CC
(Project 4730-2010-184)
Review activities:
Army AT, AV, CR4
Navy AS, CG, MC, SA, YD
Air Force - 71
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above using the
ASSIST Online database at https://assist.daps.dla.mil.
3
