AN795 Rev 5
REQUIREMENTS
Dimensions. See table I. Unless otherwise specified tolerances on decimals are ±.010, angles ±0.5°.
Configuration. See figure 1.
Dash numbers 2, 3 and 4 are inactive for new design except for use in oxygen systems and engine primer lines.
Dash numbers 5, 6, 8 and 10 are inactive for new design and are not to be used on engine primer lines.
Materials:
Brass; bars, shapes or forgings.
Corrosion resistant steel; bars, shapes or forgings.
See procurement specification.
Finish:
See procurement specification.
Identification of product. Add P before the dash number for cadmium plated brass nipple.
AN795 X X
Size
Material, finish
Drawing number
Example of Part or Identifying Number (PIN): AN795-4 tee union, brass, for .250 tubing OD.
AN795P4 tee union, brass, cadmium plated, for .250 tubing OD.
AN795C4 tee union, corrosion resistant steel, for .250 tubing OD.
Workmanship. Break all sharp edges and remove all hanging burrs and slivers which might become dislodged under
usage.
Changes from previous issue. Marginal notations are not used in this revision to identify changes with respect to the
previous issue due to the extent of the changes.
Referenced documents. In addition to MIL-DTL-6001, this document references the following:
AND10089
