AN791 Rev 7
REQUIREMENTS
Dimensions. See table I. Unless otherwise specified tolerances on decimals are ±.010, angles ±0.5°.
Configuration. See figure 1.
Dash numbers 2, 3 and 4 are inactive for new design except for use in oxygen systems and engine primer lines.
Dash numbers 6, 8 and 10 are inactive for new design except for use in oxygen systems and ground service
equipment. Dash numbers 6, 8 and 10 are not to be used on engine primer lines.
Materials:
Brass; bars, shapes or forgings.
Corrosion resistant steel; bars, shapes or forgings.
See procurement specification.
Finish:
See procurement specification.
Identification of product. Add P before the dash number for cadmium plated brass nipple.
AN791 X X
Size
Material, finish
Drawing number
Example of Part or Identifying Number (PIN): AN791-4 elbow union, brass, for .250 tubing OD.
AN791P4 elbow union, brass, cadmium plated, for .250 tubing OD.
AN791C4 elbow union, corrosion resistant steel, for .250 tubing OD.
Workmanship. Break all sharp edges and remove all hanging burrs and slivers which might become dislodged under
usage.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate where
changes from the previous issue were made. This was done as a convenience only and the Government assumes
no liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the
requirements of this document based on the entire content irrespective of the marginal notations and relationship to
the last previous issue.
Referenced documents. In addition to MIL-DTL-6001, this document references the following:
AND10089
SAE AS5201
